Gate valve thread NPT carbon steel TRIM.12 1500#
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
NPT
1500.lbs
TRIM 12
| Model: | NPT TRIM 12 | Material body: | Steel ASTM A350 LF2 |
| Connection: | Female thread NPT | Material wedge: | ASTM A182 316/316L |
| Pressure: | 255 bars see PDF | Material seat: | ASTM A479 S31600/S31603 + Stellite GR.6’ |
| Temperature: | - 46°C to + 425°C see data sheet | Operation: | Hand wheel |
| Design: | To ISO 15761 and API 602 8th |
Brand: | OMB |
| 1 side flow direction |
| Use: Petroleum industry, steam, heavy duty |
Datasheet (PDF)
| SKU | MXT-1200022000 |
|---|
| Body material | Steel ASTM A350 LF2 |
|---|---|
| Disc / Ball / Wedge | ASTM A182 316/316L |
| Seat | ASTM A479 S31600/S31603 Stellite |
